M1P Fat Tire Electric Citycoco Scooter EXW China $995

M1P Fat Tire Electric Citycoco Scooter EXW China $995

Citycoco arrow m1p is updated from the classic scooter Rooder Super M1

2000W electric Citycoco scooter for adults US and EU warehouse in stock

Rear QS or Yuma hub motor with 12″ tubeless tires

60v20ah li-ion battery of 40-60km for a single charge

Full suspension with update rear spring shock absorber

Updated front and rear lights, all LED now

Kickstand with electric power cut off

citycoco m1p (1)

Specification:

Model Rooder Mangosteen m1p
Brand Mangosteen / Rooder depends on stock
Frame material Seamless iron alloy frame
Front Tyre size 130/70-12
Rear Tyre size 215/40-12
Tyre pressure front 225kpa, rear 151kpa
Front fork ronzlla mechanical Fork
Derailleur Shift System NO
Brake type Front and Rear Disc brake
Motor power 60V, 2000W brushless motor
Max speed 45km/h for Europe, 65km/h for USA
Grade-ability 30 degrees
Max loading 200 kg
Battery 60V, 28Ah Lithium-ion removable battery
Range 55-75 km
Charger MGSD 67.2V, 5A
Charging time 5-6 hours
Working temperature -20~40℃
Waterproof standard IP54
Display LCD display
Front Shock Absorber Hydraulic shock Fork
Rear Shock Absorber Aluminum alloy spring shock absorber
Light system LED headlight, brake light, turn lights, side reflector,
Saddle height 63.5 cm
Suitable height 160-210 cm
Alarm alarm with 2 pieces remote
Product net weight 81 kg
Gross weight 92 kg
Certificates CE, FCC, ROHS, EEC, COC, CNIT, UTAC, DOT, MSDS, UN38.3
Product size 210*91*130 cm (L*W*H)
Package size 188*37.5*77 cm(L*W*H)
Package list citycoco echopper m1p, mirrors, charger, tools, user manual

citycoco m1p (3)



Mangosteen M1P 2000W 28AH Electronics:

Battery 60V/28AH removable lithium battery, 1680WH (60v*28a=1680wh), 55-75km range depends on the road condition, driver’s weight, speed and so on.
Charger 67.2V~5A MGSD quick charger, fully charged with 5-6 hours. (28ah/5a=5.6h)
Controller 60V/55A Integrated controller which supports 65kmph+ speed
Display Motor-style LCD
with charge indicator, speedometer,
odometer, trip odometer, throttle gear level, and so on.
Motor 2000W Brushless DC Geared Motor with 124 NM max torque, up to 65km/h (max speed). Motor brand: QS motor or YUMA motor.
Lights Front: Oversized headlight with turn light
Rear: Integrated taillight on the fender with brake light, and direction indicator.
Throttle Three levels of gear throttle in the default. 45kmph max for European market and 40mph(65kmph) for US market. Speed can switch betwen 45/65kmph by changing the speed limit setting.
Kickstand Electric cut off when getting on the kickstand



citycoco m1p (2)

Citycoco M1P Components:

Tires 12″ straight grain vacuum tubeless tires
Fenders Made of ABS material by MGSD.
Brakes Front and Rear Hydraulic disc brakes
Frame Seamless iron alloy frame
Front Suspension Hydraulic shock Fork
Rear Suspension Spring steel shock
Seat double seat in leather
Footrest  Foldable



citycoco m1p (4)



Mangosteen e chopper m1p Geometry:

Seat Height 63.5cm
Handlebar Height 77cm
Total Length 212cm
Handlebar Width 85cm
Rear Suspension Length 24.38cm
Footrest Size 12.44cm * 14.47cm
Kickstand Length 17cm
Controller Size 17.2cm* 9.4cm
Front Brake Hose 1100mm
Rear Brake Hose 2250mm
Rear Registration Plate Size 14.45cm * 12.5cm
Hydraulic Reservoir 24ml
Gradeability 30°
Tire Pressure Front: 225 kPa, Rear: 151 kPa
 Net Weight 76kg
Gross Weight 100kg
Maxload 200kg
Recommend Rider Height Over 140cm

citycoco m1p (5)





Rooder Technology Co., Ltd.,Founded in the year of 2018, situated in YFHC Sicence and Technology Industries Park, is a high-tech enterprise engaged in the research and development, production, sale, engineering installation and after-sales services of citycoco chopper and electric scooter.



Rooder can produce and provide various escooters. Our company has a workshop which is more than 2000 square meters and two modernized production lines which have the highest working speed in the world.



We have over 10 years’ production experience, skilled workers and excellent R&D teams, execute strict quality assurance system, and provide consummate after-sales services.



citycoco m1p (6)
